Product description
VBA-RCS8 is a wireless, long-range, Casambi-enabled control panel that brings huge flexibility to interior design as the device doesn’t require wires. The switch can be kept wherever the user wishes and gives direct access to all the Casambi lighting control functionalities.
Features
• Works with CASAMBI.
• Can control totally 4 assigned action(scene,animation,one luminaire or group).
• Dimming key have two functions by different pressing operation:
• Long press for smooth dimming.
• Tap for action on / off.
• Color temperature key have two functions by different pressing operation:
• Hold on for changing color temperature smoothly.
• Tap the left color temperature button for changing the color temperature to the warmest.
• Tap the right color temperature button for changing the color temperature to the coldest.
• Built-in battery, can be placed anywhere you want without worry about charging
Technical data
Power supply mode |
• Lithium Battery powered |
Battery |
• Type: CR2430 Lithium Coin Cell |
Battery life
|
• 2 - 5 years, depending on usage |
Operating conditions |
• Operating temperature: -20°C... +40°C • Storage temperature: -25°C... +50°C • Max relative humidity: 0...65%, non - cond. |
Radio Transceiver |
• Operating frequencies: 2.402...2.480 GHZ • Output power: -40dBm to 8dBm • Wireless range, in open air ≥ 50 m |
Physical parameter |
• Dimensions: 86*86*15 mm • Weight: 117g • Degree of protection: IP20 (indoor use only) • Color: Black, White |
Certifications |
• CE |
